Locking RAM® Tough-Dock™ for Zebra ET401 10" (RAM-HOL-ZE45PLU)
Locking RAM® Tough-Dock™ for Zebra ET401 10" (RAM-HOL-ZE45PLU)
RAM-HOL-ZE45PLU
Not what you need? See all RAM® Products here.
Features
Features
- RAM® Tough-Dock™ perfectly secures the Zebra ET401 10" enterprise tablets with Rugged Boot; includes set of keys for locking capabilities; MIL-STD 810G Shock and Vibration tested
- Compatible with C and D size RAM® 4-hole AMPS and 75mm x 75mm VESA pattern bases for attaching a double socket arm; ball and socket technology allows for near-infinite adjustability
- Compatible with RAM® Skin™, as well as C and D size RAM® 4-hole AMPS and 75mm x 75mm VESA pattern bases for attaching a double socket arm
- Space in the back of the dock to accommodate tablet add-ons such as the Expansion Back, PowerPack Battery, and GDS® Ergo™ accessories
- Backed by a 3-year warranty
Tech Specs
Tech Specs
- Hardware Included:
- (2) Keys
- (1) Side bracket for accessory mounting
- (4) #8-32 x 5/8"� Machine Screws
- (2) #8-32 x 1/2"� Machine Screws
- (6) #8-32 Nylock Nuts
- (4) #10-24 x 5/8"� Machine Screws
- (4) #10-24 Nylock Nuts
- (2) Small Cable Ties
- Hole Pattern:
- 75 x 75mm VESA
- 4-Hole AMPS: 1.181" x 1.496"
- Materials: High strength composite
- Packaging Type: Poly Bag
- Input Connector: 5.5mm DC Connector
- Input Cable Length: 1 Meter
- Certifications:
- RoHS
- WEEE
- CE
- UKCA
- Warranty: 3 year warranty
- Weight: 1.9 lb
Package Contents
Package Contents
- 1 x Locking RAM® Tough-Dock™ for Zebra ET401 10" (RAM-HOL-ZE45PLU)
Featuring charging capabilities and a key lock for theft deterrence, this RAM® Tough-Dock™ (RAM-HOL-ZE45PLU) works with the Zebra ET401 10" with Rugged Boot or RAM® Skin™. This dock allows you to keep the device charged through the pogo pin contacts when the device is docked - power is provided by connecting to the dock's 5.5mm DC power jack. The dock also allows the tablet's scanning function to work on the side, as well as tablet add-ons such as the Zebra Expansion Back and PowerPack Battery. This vehicle dock is compatible with C and D size RAM® 4-hole AMPS and 75mm x 75mm VESA pattern bases for attaching a double socket arm in order to complete your mounting solution. Take the solution a step further by taking advantage of the built-in 2-hole mounting plate compatible with RAM® 2-hole diamond base for additional device mounting such as a phone or other handheld device.
